Extech EX350 11 Function True RMS Multimeter + NCV

Extech logo

The Extech EX350 professional DMM is loaded with advanced features and functions. Low Impedance (LoZ) mode eliminates false readings caused by ghost voltages. Low Pass Filter LPF)attenuates high frequencies to reduce noise for accurate readings. The Extech EX350’s True RMS provides accurate readings when measuring distorted or noisy waveforms. Built-in Non-Contact AC Voltage Detector quickly checks for the presence of AC Voltage before testing.

PDF   Extech EX350/355 User Manual


If you would like more information regarding this product, simply email us here.
  • This field is for validation purposes and should be left unchanged.
Categories: , Tags: ,
  • Extech EX350 Professional DMMs with Non-Contact Voltage Detector, Low Impedance and Low Pass Filter
    • True RMS for accurate AC measurements
    • Backlit 4000 count  LCD display
    • Low Impedance (LoZ) prevents false reading caused by ghost voltages
    • Low Pass Filter (LPF) for accurate measurements of variable frequency drive signals
    • Built-in non-contact voltage detector (NCV) with LED indicator
    • Functions include: NCV, AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Frequency, Duty Cycle, Diode Test, Continuity
    • Data Hold, Min/Max/Max-Min, Auto Power Off
    • Relative Mode for Capacitance Zero and offset adjustment
    • Complete with test leads, two AAA batteries and general purpose bead wire temperature probe
    • Three-year warrant
Product Type Multimeter
Resistance range 0.1 to 40.00 M
Current (AC/DC) range 0.1 µA to 10.00 A
Voltage (AC/DC) range 0.01 mV to 600 V
Dimensions 8.1 x 17.5 x 4.9 cm
Frequency range 0.001 Hz to 9.999 MHz
Power Two AA batteries (included)
Accuracy ±0.5%
Duty cycle 0.1 to 99.9%
Continuity / Diode Test Audible continuity
3.2 V diode
True RMS Yes
Display 4000-count LCD, backlit
NC Voltage Detector Yes
