HT Italia PQA824 Three-phase and Single-phase Power Quality Analyzer.
Measure, record, analyze power quality on electrical installations with the 800 series meters from HT ITALIA. The PQA824 is completely designed in Windows CE technology permitting an easy and fast analysis of large quantities of data.
The unit has an innovative graphic color TFT “touch screen,” and a wide display that will meet all requests from any electrical verifier. The interface is user-friendly and help is available from each screen. A vectorial diagram feature, allows evaluation of phase angles between voltages and currents in order to understand the inductive or capacitive nature of loads on an installation.
An internal memory of 15Mbytes allows the saving of parameters and recording data over extended periods of time. The model has an USB interface to PC for the downloading and analysis using dedicated TOPVIEW Windows software. The PQA824 also permits detection of fast voltage transients and with a minimum resolution of 5µs (200kHz) and adjustable trigger thresholds. The model has rechargeable Li-Ion battery or can be used on the mains with the external 100/240V AC adapter.
The PQA 824 comes with four HTFLEX33E Flexible 3000A clamps (174mm diameter)
PQA824 Data Sheet
HT Italia PQA824 Functions:
- True-rms P-N, P-P, P-PE voltage measurements
- True-rms current on phases and neutral (4 inputs).
- Active, reactive and apparent power measurements.
- Active, reactive and apparent energy measurements.
- Power Factor.
- Maximum of 251 parameters selected at the same time.
- Integrated period selectable 1 sec. to 60 min.
- Harmonic analysis of voltage and current up to 49th component.
- Voltage anomalies with 10ms resolution.
- Numerical and graphical (waveforms) visualization.
- Histogram visualization of harmonic analysis.
- Vectorial diagram of voltages and currents.
- Flicker analysis (Pst, Plt) in compliance to EN 50160.
- Voltage unbalance in compliance to EN 50160.
- Inrush current measurements.
- Fast voltage transients with 5µs resolution.
- TFT color display with “touch screen”.
- 15 meg-byte internal memory.
- USB interface for PC.
- Windows software for analysis
- Contextual help selectable on each screen.
- Visual keyboard at display.
- Rechargeable Li-Ion battery and external AC/DC adapter.
HT Italia PQA824 Included Accessories:
- Ki-IT800: set of 5 cables with alligator clips.
- HTFLEX33D: flexible clamp 3000A AC, diameter 174mm, 4 pcs.
- A0055: 100/240V 50Hz external adapter.
- TOPVIEW2007: PC Windows software + USB cable C2007.
- BORSA2051N: carrying bag.
- PT400: Pen for touch screen display.
- Rechargeable battery Li-ION (fitted on meter).
- User manual on CD-ROM.
- Quick reference guide.
- Calibration certificate ISO9000.
