Patented FLIR MSX® (Multi-Spectral Dynamic Imaging) enhancement improves image clarity by embossing visual scene details on full thermal images, providing added context to help you accurately target potential faults and troubleshoot repairs. Record images to monitor maintenance history and reassure your customer that problems have been resolved.

The versatile and rugged FLIR TG267 infrared thermal camera enables professionals to inspect equipment and identify problems from a safe distance by visualizing the hot and cold spots that can indicate larger issues. The FLIR TG267 features a multipoint laser pointer to clearly indicate the area measured, as well as a bright LED flashlight for working in dark, difficult-to-reach spaces.

Bluetooth Low Energy (BLE) technology allows users to easily upload images and data to a mobile device for sharing and report-generation. The FLIR TG267 stores up to 50,000 images that users can play back on the 2.4-inch color display, which is more vibrant and 80-percent larger than earlier models.

IDENTIFY PROBLEMS QUICKLY

Outfit your toolbox with this combination non-contact
temperature measurement & thermal imaging camera

• Experience the difference you can make with a true 160 × 120 IR pixel imager (19,200 pixels)
• Measure a wide range of temperatures: -25°C to 380°C (-13°F to 716°F)
• Add contact-measurement readings with the included Type-K thermocouple (up to 260°C/500°F)
• Identify the exact area that you’re measuring using the bullseye laser pointer

PRODUCE CRISP THERMAL IMAGES

See the detail needed to troubleshoot fault & gauge their severity

• Diagnose problems faster with FLIR-patented MSX image enhancement
• Display and capture thermal or visual images with temperature readings
• Compare before-and-after stored images with FLIR Tools® software to demonstrate the problem and your fix
• View thermal images in your preferred colour palette on the bright 2.4-inch colour display

WORK WITH CONFIDENCE IN RUGGED ENVIRONMENTS

Take the TG267 anywhere thanks to its portable
design & protective IP54 enclosure

• Work safely and worry-free knowing that the thermal imager can withstand a 2-meter drop
• Peer into the darkness and hard-to-reach areas with the bright LED flashlight
• Upload measurement and images in the field via a METERLiNK® connection to the FLIR Tools mobile app
• Rely on the security of the world-class FLIR 2-10 warranty

FLIR TG267 Thermal Camera Specifications:

The post FLIR TG267 Infrared Thermal Camera 160 × 120 pixels appeared first on Obiat Electronics.

The FLIR  TG275 is the only spot thermal camera equipped with FLIR Multi-Spectral Dynamic Imaging (MSX^®). This patented, two-camera technology extracts high-contrast details from the images taken by an onboard visible light camera and superimposes them onto the thermal images, creating a sharper, easier-to-understand picture. Users can then easily store those images to reassure customers that a problem was fixed.

FLIR engineered the rugged TG275 to endure professional environments, whether it’s tasked with checking diesel truck engines or the hydraulic systems on construction equipment. The IP54 enclosure provides a high level of protection against dust and water.

The FLIR TG275 also includes an LED light and laser pointer, which helps guide temperature measurements by indicating the size and area of the surface being measured.

Other useful features include Bluetooth^® Low Energy (BLE) wireless technology to easily move images to a mobile device; professional reporting with FLIR Tools^®; adjustable emissivity levels; and real-time temperature updates. Also, the portable TG275 has a rechargeable battery and expandable memory.

This affordable thermal imager is ideal for diagnosing issues related to heated seats, rear window defroster, relays and switches, parasitic drain on the battery, exhaust manifolds, radiators, catalytic converters, drive train components, HVAC system (vents), and AC condensers.

FLIR TG275 KEY FEATURES:

• True thermal imager, 160 x 120 (19,200 pixels)
• Temperature range: -25°C to 550°C (-13°F to 1022°F)
• Work from a safe distance with the spotmeter (1:30)
• Patented MSX® embosses visual details on the thermal image to create a sharper, easier to understand picture
• Store up to 4 GB of data
• LED floodlight
• 2.4” display
• Rugged design, IP54 enclosure protects from dirt, dust, oil

The post FLIR TG275 Thermal Camera for Automotive Use appeared first on Obiat Electronics.

The FLIR DM166 Thermal Imaging TRUE RMS Multimeter is a must-have tool for commercial electricians, industrial electricians, electronics, and HVAC technicians. Featuring Infrared Guided Measurement (IGM) that’s powered by a built-in 80 x 60 FLIR thermal imager, the DM166 visually guides you to the precise location of potential problems.

The FLIR 166 allows professionals to efficiently test and troubleshoot electrical, electro-mechanical, and heating, ventilation, and cooling (HVAC) systems. It’s Infrared Guided Measurement (IGM) gives the added benefit of visualising heat and highlighting temperature anomalies on it’s built-in display. Whether facing cluttered wires, complex panels, or clogged condenser coils, IGM guides users without requiring any direct contact with the test site, increasing both speed and user safety.

The FLIR DM166 includes the essential measurement features you demand from a multimeter including True RMS AC/DC voltage and current, non-contact voltage detection, VFD mode, and more.

The FLIR DM166 is the most affordable multimeter with built-in thermal imaging available to date.

FLIR DM166 Thermal Imaging TRUE RMS Multimeter Specifications:

The post FLIR DM166 Thermal Imaging TRUE RMS Multimeter appeared first on Obiat Electronics.

Streamlined Reporting and Sharing
The FLIR DM285 Thermal Imaging Multimeter uniquely features Bluetooth™ which enables wireless data transfer by connecting to the FLIR Tools Mobile app on compatible mobile devices. The FLIR DM285 is also compatible with the new FLIR InSite™ workflow management tool that allows you to prepare efficient survey routes, maintain accurate documentation, share information with clients, and file instant reports.

Solve Challenging problems Easily
The FLIR DM285 Thermal Imaging Multimeter features 18 measurement functions including True RMS, LoZ, and NCV, you can verify potential issues with trusted readings every time — even for the most complex measurements. The FLIR DM285 also includes a thermocouple input and allows you to view thermal and electrical measurements simultaneously.

The post FLIR DM285 Thermal Imaging Multimeter appeared first on Obiat Electronics.

TG167 Features and Functions:

• see the heat and speed up troubleshooting

• know where to measure temperature

• grab and go simplicity—no special training required

• pocket portable to fit a crowded tool bag

• rugged and reliable

• IR resolution 80 × 60 pixels

• Thermal sensitivity/NETD < 150 mK

• Field of view (FOV) 25° × 19.6°

• Minimum focus distance 0.1 m (4 in.)

• Image frequency 9 Hz

• Focus Focus free

• Detector type Focal plane array (FPA), uncooled microbolometer

• Spectral range 8 – 14 µm

• Display 2.0 in. TFT LCD

• Object temperature range –25 to +380 °C (–13 to +716 °F)

• Color palettes: hot iron, rainbow, grayscale

• Emissivity correction: 4 pre-set levels with custom adjustment of 0.1 – 0.99

• Memory type Micro SD card 75 000 pictures with included 8 GB Micro SD card

• Laser Dual diverging lasers indicate the temperature measurement area, activated by pulling the trigger
• Battery type Rechargeable Li ion battery, 3,7 V

The post FLIR TG167 Imaging IR Thermometer appeared first on Obiat Electronics.

Reduce energy costs.
Ideal for seasonal home inspections

• Find heat loss around doors, floors, walls, pipes, or windows
• Locate spots where insulation is missing
• Find drafts

Solve household heating/cooling issues.
Save time and money on troubleshooting

• Check HVAC performance and functionality
• Discover electrical issues affecting home appliances
• Confirm that refrigerator settings are correct, and food is stored at a safe temperature

Point-and-click simplicity.
Aim the thermal camera at a target then click to freeze the image. No special training required.

• Pocket-portable size
• Ergonomic design
• Standard, easy-to-replace AAA batteries

Specifications

The post FLIR TG130 Spot Thermal Camera appeared first on Obiat Electronics.
