EXTECH SDL800 Vibration Meter/Datalogger

Extech_logo_sml

Records data on an SD card in Excel® format

for easy transfer to a PC for analysis

Features:

  • Remote vibration sensor with magnetic adapter on 47.2″(1.2m) cable
  • Wide frequency range of 10Hz to 1kHz
  • Basic accuracy of ±(5% + 2 digits); Meets ISO2954
  • RMS, Peak Value or Max Hold measurement modes
  • Adjustable data sampling rate
  • Offset adjustment used for zero function to make relative measurements
  • Large backlit LCD
  • Stores 99 readings manually and 20M readings via 2G SD card
  • Record/Recall MIN, MAX, Data Hold and Auto power off
  • Built-in PC interface
  • Complete with remote sensor, magnetic mount, 6 x AA batteries, SD card, and hard carrying case

PDF   Extech SDL800 User Manual

Authorised Australian Distributor

CE   3 Years

If you would like more information regarding this product, simply email us here.
  • This field is for validation purposes and should be left unchanged.
SKU: EXTECH SDL800 Categories: , , Tags: , ,

The Extech SDL800 Vibration Meter displays and stores vibration readings of Acceleration, Velocity and Displacement. Supported measurement units are meters/s2 , ft/s2 , g, mm/s, cm/s, in/s, mm and inch. Logged data readings are stored on an SD card for transfer to a PC. This meter is shipped fully tested and calibrated and, with proper use, will provide years of reliable service

  • Datalogger date/time stamps and stores readings on an SD card in Excel® format for easy transfer to a PC
  • Selectable data sampling rate: 1 to 3600 second
  • Manually datalog up to 99 readings
  • Basic accuracy of ±(5% + 2 digits)
  • RMS, Peak Value or Max Hold measurement modes
  • Data Hold freezes the reading in the display
  • Zero function
  • Auto shut-off saves battery life
  • Meets ISO2954

Basic settings at a glance

To view the current configuration of the meter with regard to time, date, and datalogging sampling rate press the SET button momentarily. The meter will now display the configuration in quick succession. If the information is missed on the first try, simply press the SET button again until all of the information is noted.





 Specification
Acceleration 656ft/s2, 200m/s2, 20.39g
Velocity 7.87in/s, 200mm/s, 19.99cm/s
Displacement 0.078in, 2mm (peak-to-peak)
Resolution 1ft/s2, 0.1m/s2, 0.01g; 0.01in/s, 0.1mm/s, 0.01cm/s, 0.001in, 0.001mm
Basic accuracy ±(5%+2 digits)
Memory 20,000K data records using 2G SD card
Dimensions 7.2 x 2.9 x 1.9″ (182 x 73 x 47.5mm)
Weight 21.1oz (599g)
